Install a DPCC
Alternatively, to prepare the server for cold service, see
Service" on page
Ensure the top of the DPCC is closed and secured and the lever on the front of
2.
the DPCC is in its fully open position.
3. Align the DPCC with the vacant slot.
The connector (back) side of the DPCC faces inward toward the server.
4. Slide the DPCC into the slot until it stops.
This leaves the DPCC protruding slightly from the back of the server. Do not attempt push the
DPCC inward beyond this point.
5. Rotate the lever on the DPCC upward until it locks into place.
Caution -
194 Oracle Server X5-8 Service Manual • December 2015
98.
Pinch point. Keep fingers away from the backside of the lever when closing it.
"Prepare the Server for Cold
