SSANGYONG 1999 Musso Service Manual page 1323

CLOCK SPRING
General Specification
Voltage
Rating Operating Voltage
Current Rating
Air Bag Circuit Resistance
Isolating Resistance
Rotating Range
Notice
Clock spring can not be repaired.
Do not disassemble or modify.
To adjust to the center position, rotate clockwise until it
stops and then rotate it counterclockwise 2.3 ± 0.2
revolutions and align marks. If not, airbag system can
not work normally and driver can be injured seriously.
SUPPLEMENTAL RESTRAINT SYSTEM(SRS) 8B-19
Air Bag
Horn (Relay)
Remote Control (Electronic Circuit)
DC 12V
DC 6 - 18V
10 - 30mA(6A,0.1second)
200 - 220mA
15mA
0.16 - 0.38W (-40°C - 85°C)
5MW
2.7 - 3.1 Rotation from neutral
Position to Both Sides
