SSANGYONG 1999 Musso Service Manual page 1364

9B-12 LIGHTING SYSTEM
Rear Combination Lamp
Removal & Installation Procedure
1. Open the tailgate and remove the inner cover of the rear
combination lamp.
2. Unscrew 4(8mm) nuts of tail/stop lamp and turn signal lamp
assembly.
3. Unscrew 6(8mm) nuts of tail/stop lamp and back-up
lamp assembly.
4. Disconnect each connectors and remove the rear
combination lamp. Replace with specified bulb, if
necessary.
Notice
Refer to lamp specification.
Tail/stop and turn signal lamp
Tail/stop Lamp and backup lamp
