Configuring call-progress-tone profiles
Each call-progress-tone consists of a sequence of different tones and pauses. Arbitrary tone cadences can be
configured. With these parameters all country specific tones can be defined. Tone configuration knows only
one command that have to be used repeatedly. The sequence in which the commands are entered (or appear in
the config file) defines the sequence in which the corresponding elements are played.
Procedure: To configure a tone-set profile
Mode: Configure
Step
1
node (cfg)#profile call-progress-tone
name
2 node (pf-callp)[ name ]#play duration
frequency1 level1 [frequency2 level2]
3 node (pf-callp)[ name ]#no play duration
4
node (pf-callp)[ name ]#...
5 node (pf-callp)[ name ]#flush-play-list
Example: Define the Belgian special information tone
The first line defines the first element of the tone: 330ms of 950Hz at –4dB. The second line the element that
is played when the first element has finished: 330ms of 144Hz at –4dB, and so on. The last line defines a pause
of 1 second after the three tones. The cadence is repeated infinitely.
node(cfg)#profile call-progress-tone belgianSpec
node(pf-callp)[belgian~]#play 330 950 -4
node(pf-callp)[belgian~]#play 330 1400 -4
node(pf-callp)[belgian~]#play 330 1800 -4
node(pf-callp)[belgian~]#no play 1000
Tones and pauses can be arbitrarily sequenced up to a number of 10 elements per call-progress-tone. The
default call-progress-tone is an empty tone. The total number of different play elements across all configured
call-progress-tones must not exceed 15 (an error is thrown if it does). If the call-progress-tone consists of only
one element, this element has infinite duration. The duration parameter is ignored in this case.
Configure tone-set profiles
A tone-set profile maps one call-progress-tone profile to each internal call-progress-tone. A tone-set profile typ-
ically includes all the call-progress-tones for one country.
Tone configuration task list
Command
34 • Tone configuration
Purpose
Creates a call-progress-tone profile with name
name and enters call-progress-tone configura-
tion mode.
Defines a tone with duration duration , fre-
quency frequency1 and volume level1 . If a sec-
ond frequency is defined both frequencies are
played in parallel and for the same duration
Defines a pause of duration milliseconds
Repeat step 2 and/or step 3 to define a tone
sequence. Always when you enter a play or
no play command, it is appended to the
already existing tone.
Resets the tone cadence. Same as deleting
and re-creating the tone.
