SmartWare Software Configuration Guide
Mode: Configure
Step
node (cfg)#port ethernet slot port
1
node (prt-eth)[ slot/port ]#map cos layer 2 class of service value
2
to traffic class name
If the frame format is set to standard, the
the data traffic.
The and
cos rx-map cos tx-map
entered as additional command argument. The command syntax is:
• cos rx-map—layer 2 class of service value as service class value
• cos tx-map—service class value as layer 2 class of service value
Do the following to configure the class of service map:
1. Configure the class of service map table for the outgoing data traffic. Every provided service can be
mapped to a Class of Service.
2. Configure the class of service map table for the incoming data traffic. Every received Class of Service can be
assigned to a service type.

Adding a receive mapping table entry

The receive mapping table defines the conversion of receiving Layer 2 CoS to service class value into a firm-
ware-specific service class value. Each conversion is stored as a mapping table entry, so the receive mapping
table consists of several mapping table entries.
This procedure describes how to add a receive mapping table entry.
Mode: Configure
Step
node (cfg)#port ethernet slot port
1
node (prt-eth)[ slot/port ]#cos rx-map layer
2
2 class of service value as service class value
Example: Adding a receive mapping table entry
The following example shows how to add a receive mapping table entry, which converts a layer 2 class of ser-
vice value of 2 into a service class value of 4 for the Ethernet port on slot 0 and port 0 of a SmartNode.
node(cfg)#port ethernet 0 0
node(prt-eth)[0/0]#cos rx-map 2 as 4
Ethernet port configuration task list
Command
cos default
commands above need service class mapping table entries, which has to be
Command
12 • Ethernet port configuration
Enters Ethernet port configura-
tion mode for the interface on
slot and port
Selects the layer 2 CoS to traffic-
class mapping. The traffic class
name can be freely chosen.
command value defines which class of service to use for
Enters Ethernet port configuration mode for the
interface on slot and port .
Adds a receive mapping table entry, which con-
verts a layer 2 class of service into a service class
value .
Purpose
Purpose
137
