SmartWare Software Configuration Guide
Mode: Administrator execution
Step
node (cfg)#port serial slot port
1
node (prt-ser)[ slot/port ]#no shutdown
2
node (prt-ser)[ slot/port ]#show port serial Displays the serial interface configuration.
3
Example: Enabling an interface
The example shows how to enable the built-in serial interface on slot 0 and port 0. Check that State is set to
OPENED in the command output of
node(cfg)#port serial 0 0
node(prt-ser)[0/0]#no shutdown
node(prt-ser)[0/0]#show port serial
Serial Interface Configuration
------------------------------
Port
State
Hardware Port
Transmit Edge
Port Type
CRC Type
Max Frame Length: 2048
Recv Threshold
Encapsulation
Configuring the serial encapsulation type
The synchronous serial interface supports the Frame Relay and PPP serial encapsulation method.
To set the encapsulation method used by a serial interface, use the
configuration command.
This procedure describes how to set the encapsulation type of the serial interface.
Mode: Administrator execution
Step
node (cfg)#port serial slot port
1
node (prt-ser)[ slot/port ]#[no] encapsulation {
2
framerelay | ppp }
node (prt-ser)[ slot/port ]#show port serial
3
Example: Configuring the serial encapsulation type
The following example enables Frame Relay encapsulation for the serial interface on slot 0 and port 0. Check
that in the command output of
node(cfg)#port serial 0 0
Serial port configuration task list
Command
show port serial
: serial 0 0 0
: OPENED
: V.35
: normal
: DTE
: CRC-16
: 1
:
Command
show port serial
Selects the serial interface on slot and port
Enables the interface
.
encapsulation
Selects the serial interface on slot and
port .
Sets the encapsulation type for the
selected interface.
Displays the serial interface configuration.
Encapsulation is set to framerelay.
14 • Serial port configuration
