Test the call router configuration
After activating the call router configuration you can test the call router by simulating a route lookup as if a call
is routed to a table. You have to execute the test call-router command and specify all necessary call properties
together with the routing table you want to test.
Note
You must activate the call router using the
Procedure: To test the call router configuration
Mode: Context CS
Step Command
node (ctx-cs)[ switch ]#debug call-
1
router detail level
2 node (ctx-cs)[ switch ]#test call-router
table-name [ property-type property-
value ]
Example: Create and test a routing table
node(cfg)#context cs
node(cts-cs)[switch]#routing-table called-e164 TEST
node(rt-tab)[TEST]#route 1 dest-interface IF1
node(rt-tab)[TEST]#route 1[0-4] dest-interface IF2
node(rt-tab)[TEST]#route 11 dest-interface IF3
node(rt-tab)[TEST]#route 111T dest-interface IF4
node(rt-tab)[TEST]#route default dest-interface IF5
node(rt-tab)[TEST]#exit
node(ctx-cs)[switch]#no shutdown
node(ctx-cs)[switch]#debug call-router detail 5
node(ctx-cs)[switch]#test call-router TEST called-e164 123
Parameters
==========
Time:
Result:
Destination:
Timeout:
Property Containers
-------------------
Properties
Properties
E164-Number:
Properties
16:55:33 CR
16:55:33 CR
16:55:33 CR
(no timeout) matches 1
Call router configuration task list
> [switch] Routing-Lookup:
> Find best-matching called-element in table test
> 01: Prefix Timeout Expression: E164-Number of 123 completely
no shutdown
Enables the call router debug monitor. Chose level 5 to trace
route lookups in detail.
Tests the routing or mapping table table-name with the speci-
fied call property. You can repeat the optional section multi-
ple times and thus enter as many call properties as you want.
2004-03-02T16:55:33<-- Time of the lookup
route-found-place-call<-- Lookup result
IF2<-- Dest. Interface
0<-- Digit-Coll. TO
123 (String)<-- CdPN after lookup/change
33 • Call router configuration
command first.
Purpose
