SmartWare Software Configuration Guide
routing table
route 911 dest-service prio.high
route default dest-service prio.low1
SIP
By default, the service drops any lower priority calls if a higher priority call fails. However, you have the option
to limit the number of lower priority calls to be dropped if a higher priority call fails. It also blocks new lower
priority calls for a configurable time after a higher priority call failed.
The following procedure demonstrates how to configure a priority service.
Mode: context cs
Step
1 node (ctx-cs)[ctx- name ]# service
priority <svc-name>
2 node (svc-prio)[svc-name]# port
<port-name>
3 node (port)[port- name ]# route
dest-....
4 node (port)[port- name ]# service
(Optional)
priority
node (port)[port- name ]# exit
5
6
7 node (svc-prio)[svc-name]# max-
(Optional)
calls-to-drop <calls>
8 node (svc-prio)[svc-name]#
(Optional)
quiesce-time <seconds>
9 node (svc-prio)[svc-name]# retry-
(Optional)
timeout <seconds>
Note
Although this service improves the probability that higher priority calls can
be established successfully, there is no guarantee that a higher priority task
can be established successfully at any time.
Call router configuration task list
high
low1
Figure 65. Priority service diagram
Command
service hunt-group
services priority (prio)
priority: 2
priority: 0
priority: 0
low2
Create a priority service.
Create a port within the service.
Define the routing destination for calls received on this
port.
Define the priority for calls received through this port.
(The default priority level is 0)
Leave the port configuration mode
Repeat steps 2 to 5 for any additional calls you need to
create.
Define the maximum number of lower priority calls to be
droppedif a higher priority call fails. (Default is to drop
any lower priority calls.)
Define the time for which lower priority calls are
blocked after a higher priority call failed. (Default is
15 seconds.)
Define the time for which the service waits after a
higher priority call failed until it tries to establish it for a
second time. This allows resources used by dropped
lower priority calls to get available again. (Default is
3 seconds.)
33 • Call router configuration
