7.5.7

Automatic Uplink Power Control (AUPC) Commands / Queries

The instruction codes that follow are valid only when the SLM-5650C Satellite Modem type has been set to AUPC.

Note: Always wait three (3) seconds between consecutive remote modem command/query polls. If Local AUPC is not enabled, queries

will return the last known condition. A request for status from the remote modem will then be transmitted, ensuring that the next query will

return current status.

Command

Arguments

Parameter

(Instruction

for Command

Code and

or Response

Type

to Query

Qualifier)

AUPC Eb/No

AET=

4 bytes

Target Set

Point

AUPC

AMN=

5 bytes

Minimum

Power Level

AUPC

AMT=

3 bytes

Maximum

Tracking

Rate

AUPC

AMX=

5 bytes

Maximum

Power Level

AUPC

ANP=

5 bytes

Nominal

Power Level

Serial Remote Control

Description of Arguments

Command or Query.

AUPC Eb/No Target, where:

xx.x = AUPC Eb/No Target, 3.2 to 16.0 dB.

Example: AET=13.4

Command or Query.

Minimum Tx Output power level, where:

s=sign ( + / – )

xx.x = Tx Output power level, +10.0 and –40.0 dBm.

Example: AMN = –13.4

Command or Query.

AUPC Maximum Tracking Rate, where:

x.x = Maximum Tracking Rate, 0.5 to 6.0 dBm/minute in increments of

.5.

Example: AMT=0.5

Command or Query.

Maximum Tx Output power level, where:

s=sign ( + / - )

xx.x = Tx Output power level, +10.0 and –40.0 dBm.

Example: AMX=-13.4

Command or Query.

Nominal Tx Output power level, where:

s=sign ( + / - )

xx.x = Tx Output power level, +10.0 and –40.0 dBm.

Example: ANP=-13.4

SLM-5650C / SLM-5650C-ODU Satellite Modem

Response to

Command

AET=

AET?

AET*

AET#

AMN=

AMN?

AMN*

AMN#

AMT=

AMT?

AMT*

AMT#

AMX=

AMX?

AMX*

AMX#

ANP=

ANP?

ANP*

ANP#

7–32

Revision 1

Query

(Instruction

Response to Query

Code and

Qualifier)

AET?

AET=xx.x
