Chapter 7: Installing and Removing Internal Drives and Front Module Parts
168

Removing the Blank Panel

After installing a new option drive, remove a blank panel from the bezel.
1. Place the bezel on a flat surface with the door facing up.
2. Open the door, as shown in Figure 7-9.
3. Locate the blank panel covering the drive bay where you installed the option drive.
Figure 7-9 Opening the Bezel Door
Vent
Blanking panels
