Chapter 4: Installing and Removing PCI Boards

Preparing the Workstation

72
To install or remove a PCI board, power off your workstation, remove any cables
attached to the PCI module, and then attach the wrist strap.
1. Open the cover and press the power button (see A in Figure 4-3).
2. Unplug the power cable from the electrical outlet (B).
3. Press the monitor power switch to turn off your monitor (C).
B
Power cable
Powering Off the Octane2 Workstation
Figure 4-3
Power button
A
C
Power switch
