Preparing the Workstation to Remove the Frontplane Module

The procedure for replacing the frontplane module includes a number of steps from
earlier sections of this guide (as described below). Bookmarking these sections can help
you organize this task. For help identifying Octane2 components, refer to the illustrations
in Chapter 1. Make sure you have the new part nearby before beginning the replacement
procedure.
1. Go to "Shutting Down and Powering Off the System" on page 161, then follow the
instructions for "Removing the Bezel" on page 162.
2. Face the back of your workstation, then follow these steps:
Disconnect the system module from the chassis by unscrewing the captive
screws and pulling the module an inch or two from the chassis, or remove it (for
more information, see "Removing the System Module" on page 36).
Disconnect the PCI module (if installed) from the chassis by unscrewing the
captive screws and pulling the module an inch or two from the chassis, or
remove it (for more information, see "Removing the PCI Module" on page 75).
Disconnect the power supply from the chassis by unscrewing the captive
screws and pulling the power supply an inch or two from the chassis, or remove
it (for more information, see "Removing the Power Supply" on page 64).
Disconnect the XIO Tri-Module from the chassis by unscrewing the captive
screws and pulling the module an inch or two from the chassis, or remove it (for
more information, see "Removing the XIO Tri-Module" on page 114).
Removing and Replacing the Frontplane Module
181
