Table B-13 Female Db9 To Female Db9 Adapter Cable Pinout - Silicon Graphics OCTANE2 Owner's Manual

Appendix B: Technical Specifications
236
Table B-13 shows the pinout for a female DB9 to female DB9 adapter cable.
Table B-13 Female DB9 to Female DB9 Adapter Cable Pinout
Female DB9 Female DB9 Connected to Peripheral
Connected to
Octane2
1 Unused
2 To DB9 -2 (RxD-)
3 To DB9-8 (TxD-)
4 Unused
5 To DB9-6and DB9-4 (GND)
6 To DB9-7 (RxD+)
7 To DB9-3 (TxD+)
8 Unused
9 Unused
For more detailed information, see the serial man page. To access it, place the
Note:
cursor in an IRIX shell and enter:
man serial
Or, access Man Pages by choosing Toolchest > Help > InfoSearch > and enter:
man serial
