Microphone Specifications
Table B-21 shows the microphone specifications.
Table B-21 Microphone Specifications
Microphone Jack
Connector
Power
Type
Speaker Specifications
Table B-22 shows the speaker specifications.
Table B-22 Speaker Specifications
Speakers
Rated power
Frequency range
Magnetic flux leakage
Input impedance
Signal connector
Power connector
3.5 mm stereo mini
+5 V phantom power on tip
Unidirectional electret condenser
3 W(average) per channel
180 Hz - 15K Hz
<50 mGauss @2 cm
150 ohms
3.5 mm stereo mini
2.5 mm mono micro
Physical Environment Specifications
