Figure 2-10 Placing The Compression Cap On The Compression Connector - Silicon Graphics OCTANE2 Owner's Manual

Chapter 2: Installing and Removing the CPU and Memory
40
5. Place a cap on each compression connector on the back of the system module, as
shown in Figure 2-10 (compression connector caps are included with your
workstation.)
Caution - Do not touch
Figure 2-10 Placing the Compression Cap on the Compression Connector
The heat sinks on the CPU and system module get very hot. Wait 5
Warning:
minutes before touching them, and then test before touching them.
