2. Completely remove the screws that secure the I/O door to the PCI module, as
shown in Figure 4-21.
Removing the I/O Door Screws
Figure 4-21
3. Slide open the I/O door to expand the PCI module, as shown in Figure 4-22.
Figure 4-22 Opening the I/O Door
I/O door expansion device
Installing a PCI Board
85
