4. Press down on the blank panel covering the desired drive bay, as shown in
Figure 7-10.
The blank panel pops out the back of the bezel.
Store the blank panel in a safe place. You must replace it if you remove the drive.
Caution: To prevent damage to your workstation, you must place a blank panel in
the bezel if you remove a drive. The blank panel ensures proper airflow through the
workstation.
Figure 7-10 Releasing the Blank Panel
Go to "Reinstalling the Bezel" on page 195.
Installing and Removing Internal Drives
Vent
Blanking panels
169
