Reinstalling the System Module

1. Remove the caps on the compression connectors on the back of the system module,
as shown in Figure 2-22. Do not touch the system module compression connectors
as you lift the module into the workstation.
Caution: Do not insert the system module into the workstation unless the power
cable is unplugged from the electrical socket. If you insert the system module into
the Octane2 workstation with the power cable connected to an electrical socket, the
workstation will be damaged.
Caution - Do not touch
Figure 2-22 Removing the Compression Connector Cap

Reinstalling the System Module

53
