Chapter 1: Getting Started
10
3. Place the speakers on either side of the monitor, as shown in Figure 1-7.
4. Connect the left (passive) speaker to the right (active) speaker. Use the port
labeled L.
Right (active) speaker
Figure 1-7
Attaching the Speaker-to-Speaker Cable
Power
Left (passive) speaker
