Chapter 7: Installing and Removing Internal Drives and Front Module Parts
174
To replace the system drive, follow these steps:
1. Locate the system drive.
2. Raise the handle to a horizontal position, as shown in Figure 7-15.
Figure 7-15 Unlocking the System Drive
3. Pull the system drive out of your workstation, as shown in Figure 7-16.
Option drive bays
System drive
Figure 7-16 Removing the System Drive
Option drive bays
System drive
Light module
