Appendix B: Technical Specifications
244
Headphone Specifications
Table B-23 shows the headphone specifications.
Table B-23 Headphone Specifications
Headphones
Recommended impedance
Connectors
Analog Line Level Audio Specifications
Table B-24 shows the analog audio line level specifications.
Analog Line Level Specifications
Table B-24
Specifications
Line level
0dBFS maximum
PCI Module Power Specifications
Total power for the PCI module (the sum of power for all boards from all power supply
rails) must not exceed 45.0W (average 15.0W per board).
The Octane2 PCI module is a 5V system environment.
Table B-25 PCI Module Power Specifications
Power Supply Rail
3.3V
5.0V
12.0V
-12.0V
35 ohms
3.5 mm stereo mini
Line In
-10dBV
+10dBV to -22dBV
Maximum Current
10.0A
9.0A
1.5A
0.3A
Line Out
-10dBV
6.5dBV ± 0.5dBV
Maximum Power
33.0W
45.0W
12.0W
3.6W
