Chapter 1: Getting Started
12
6. Connect the active speaker to your workstation, using the cable with two male
connectors on the end, as shown in Figure 1-9.
Connect the smaller male connector to the speaker power port.
Attach the larger male connector to the speaker port.
Connecting the Speaker and Power Cables
Figure 1-9
Speaker
Power
