Chapter 4: Installing and Removing PCI Boards

About the PCI Module and Boards

70
To install PCI boards, you must use the PCI module. The PCI module is an optional
Octane2 component that allows you to install and remove PCI boards without opening
your workstation. If your workstation does not have a PCI module installed, a blank
panel covers the module slot, as shown in Figure 4-1.
PCI blank panel
Figure 4-1 Workstation without the Optional PCI Module
If your workstation has a PCI module installed, it protrudes from the rear of the
workstation, as shown in Figure 4-2.
