Chapter 7
7. Installing and Removing Internal Drives and Front
Module Parts
This chapter shows you how to remove and install an internal drive, light module,
frontplane module, system fan, and the external plastics located behind the bezel on the
front of your workstation. Installing an internal drive is an easy task that requires no tools
or screws. It is unlikely that you will need to replace the light module, frontplane module,
system fan, or external plastics. Replacing any of these components is a complicated and
lengthy task; it is best performed by an experienced user.
The following topics are covered in this chapter:
• "Installing and Removing Internal Drives" on page 160
• "Removing and Replacing the Light Module" on page 177
• "Removing and Replacing the Frontplane Module" on page 180
• "Removing and Replacing the System Fan" on page 187
• "Removing and Replacing the Plastics: Top and Base" on page 190
159
