Connecting SCSI Devices
1. Connect a single device, or the first of several devices, as shown in Figure 6-6.
Connect one end of the SCSI cable to your workstation's SCSI port or to the
back of another SCSI device.
Connect the other end of the SCSI cable to one of the SCSI connectors on the
back of the device and secure the clips on each side of the connector.
SCSI
Figure 6-6
Connecting an External SCSI Device to the Octane2 Workstation
Installing External SCSI Devices
139
