Removing and Replacing the Light Module

3. You can also use the System Manager to verify installation of the drive.
Choose Toolchest > System > System Manager > Hardware and Devices > Disk
Manager to display a list of installed drives.
Choose the new internal drive, then click the Get Info button.
If the new internal drive does not appear in the list, power off your system, and
make sure the drive is completely seated in its slot. Then restart your system
and check the System Manager list again.
The light module provides the light for the light bar on the front of the Octane2
workstation. The light module is located on the sheet-metal face, behind the bezel, as
shown in Figure 7-19.
Light module
Figure 7-19 Locating the Light Module

Removing and Replacing the Light Module
