Chapter 4: Installing and Removing PCI Boards
88
8. Reinstall the PCI module door, as shown in Figure 4-27.
Figure 4-27
Reinstalling the PCI Module Door, as shown in Figure 4-28.
9. Tighten the PCI module door screws.
Tightening the PCI Module Door Screws
Figure 4-28
Go to "Installing the PCI Module" on page 100.
Release hinge
