CDM-625 Advanced Satellite Modem
Ethernet-based Remote Product Management
6.3

SNMP Interface

The Simple Network Management Protocol (SNMP) is an Internet-standard protocol for managing
devices on IP networks. An SNMP-managed network consists of three key components:
The managed device – This includes the CDM-625 Advanced Satellite Modem.
•
The SNMP Agent – The software that runs on the CDM-625. The CDM-625 SNMP Agent
•
supports both SNMPv1 and SNMPv2c.
The user-supplied Network Management System (NMS) – The software that runs on
•
the manager.

6.3.1 Management Information Base (MIB) Files

MIB files are used for SNMP remote management of a unique device. A MIB file consists of a
tree of nodes called Object Identifiers (OIDs). Each OID provides remote management of a
particular function. These MIB files should be compiled in a user-supplied MIB Browser or SNMP
Network Monitoring System server.
The following MIB files are associated with the CDM-625:
MIB File/Name
(where * is revision letter)
FW10874-2*.mib
ComtechEFData Root MIB file
FW-0000083*.mib
CDM-625 MIB file
FW-0000084*.mib
CDM-625 Traps MIB file
FW-0000345*.mib
IP Packet Processor MIB file
FW10874-8*.mib
CSAT-5060 Transceiver MIB
file
FW10874-9*.mib
KST-2000A/B Transceiver
MIB file
FW-0000165*.mib
DistantEnd CDM-625 MIB file
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data products
and consists of only the following OID:
Name:comtechEFData
Type:MODULE-IDENTITY
OID:1.3.6.1.4.1.6247
Full path:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
MIB file consists of all of the OIDs for management of the modem functions
Trap MIB file is provided for SNMPv1 traps common for modem.
MIB file consists of all of the OIDs for management of the optional IP Packet
Processor functions.
MIB file consists of all of the OIDs for management of the CSAT-5060 Transceiver
connected to the CDM-625 modem through FSK.
MIB file consists of all the OIDs for management of the KST-2000A/B Transceiver
connected to the CDM-625 modem through FSK.
MIB file consists of a subset of the CDM-625 MIB with all OIDs used manage to a
distant-end CDM-625. SNMP "gets" and "sets" are sent to the local CDM-625 and
EDMAC3 is used to communicate efficiently with the distant end modem.
