Comtech EF Data CDM-625 Installation And Operation Manual page 431

CDM-625 Advanced Satellite Modem
IP Packet Processor Option
Step Task
6 Prepare t he I P P acket P rocessor C ard f or i nstallation b y
aligning i ts r eceptacle w ith t he m ating c onnector o n t he
modem's framing board.
Plug t he c ard f irmly i nto t he connector – take c are no t t o
damage a ny t op-mounted c omponents. S imilarly, be su re
not t o d amage t he b ottom of t he card o n t he chassis'
mounting bosses while plugging the card receptacle into its
mating connector.
Installation i s c omplete once t he c able c onnector i s f ully
engaged w ithin its mating receptacle, a nd the mounting
holes at the front of the card are aligned with the mounting
boss threaded holes.
7
Use the screwdriver to secure the IP Packet Processor card
to the chassis with its provided mounting hardware (2X 4-
40 x 1/4 pan head screws).
18–13
Revision 13
MN-CDM625
