CDM-625 Advanced Satellite Modem
Appendix F
F.5.1.2.1.3 Home > Outdoor Unit (ODU) > CSAT-5060 > Unit Settings 1/2, 2/2
Open the Unit Settings 1/2 page or the Unit Settings 2/2 page from the nested CSAT-5060
submenu.
The Unit Settings 1/2 page contains the following options:
Hot
Dialog Window
Key
A
Unit Mute Mode
B Unit Auto Fault Recovery
C
Unit Cold Start
The Unit Settings 2/2 page contains the following options:
Hot
Dialog Window
Key
A Unit Ext Ref Fault Logic
B Unit Ref Osc Adjust
C Circuit ID
Typical for either page, press a hot key to open a dialog window. Otherwise, press [ESC] to
return to the nested CSAT-5060 submenu.
Option Entry
Use the ↑↓ arrow keys to select Unmuted After Freq Change or
Muted After Freq Change
Use the ↑↓ arrow keys to select Disabled or Enabled
Use the ↑↓ arrow keys to select Disabled or Enabled
Option Entry
Use the ↑↓ arrow keys to select No Summary or Summary
Enter a value from 0 to 255
Enter an identifying label for the ODU here
