CDM-625 Advanced Satellite Modem
Appendix E
E.3.3.9 Home > Modem > MEO (Medium-Earth Orbit)
MEO is non-functional when the optional Carrier-in-Carrier (CnC) card is installed.
CDM-625 modems are configurable for continuous pairing as Primary and non-Primary Modems
in an Antenna Handover System when the MEO (Medium Earth Orbit) feature is enabled. Open
the MEO page from the Modem submenu. This page contains the following options:
Hot
Dialog Window
Key
A
MEO Enable
B
Antenna Handover Enable
C
Antenna Handover Mode
D
Antenna Handover DPD
E
Antenna Handover Port
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
Option Entry
Typical for either entry – Use the ↑↓ arrow keys to select Disabled
or Enabled
Use the ↑↓ arrow keys to select Manual or Auto
Enter a Differential Path Delay value from -30 to 30
Enter a value from 1001 to 65535
E–35
Revision 13
MN-CDM625
