Comtech EF Data CDM-625 Installation And Operation Manual page 492

CDM-625 Advanced Satellite Modem
Appendix D
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Rx Data Rate RDR= 9 bytes
Rx Symbol RSR= 9 bytes,
Rate numeric
Rx RFQ= 9 bytes
Frequency
Exception –
600 Emulation:
8 bytes
Rx Sub-Mux RMX= 1 byte, 0 or 1
on/off
Rx Sub-Mux RMR= 2 bytes,
Ratio numeric
Description of Arguments
Command or Query (Query only in IP-ACM).
Rx Data Rate, in kbps, between 18 kbps to 25 Mbps.
Resolution=1 bps
Example: RDR=02047.999.
Additional auxiliary G.703 sub-rates are available, selected using:
00512.AUX
01024.AUX
02048.AUX
If set for QDI (Quad D&I), RDR is query only.
The connectors used for the Aux rates are IDI/DDO.
These Aux rates are not available with D&I or IDR.
Query only (Command or Query in IP-ACM).
Allows remote access to the Rx Symbol Rate in the form ddddd.ddd
Note: Symbol Rate ranges in IP-ACM = 37 ksym/sec to 4100 ksym/sec
Command or Query.
Frequency ranges:
50 MHz to 180 MHz, and
950 MHz to 1950 MHz (L-Band – FAST option)
950 MHz to 2150 MHz (Top card hardware Revision 2)
Resolution=100Hz.
Note: The CDM-625 supports 70,140 MHz bands and L-Band.
Example: RFQ=0950.9872
Command or Query.
Rx Sub-Mux in the form x, where:
0=Off
1=On
Command or Query.
Rx Sub-Mux Ratio (IP/Synchronous Interface) in the form xx, where:
00=1/9 08=2/5
01=1/8 09=3/7
02=1/7 10=1/2
03=1/6 11=3/5
04=1/5 12=2/3
05=1/4 13=3/4
06=2/7 14=4/5
07=1/3 15=1/1
Example: RMR=01 (Selects ratio 1/8)
16=5/4 24=7/2
17=4/3 25=4/1
18=3/2 26=5/1
19=5/3 27=6/1
20=2/1 28=7/1
21=7/3 29=8/1
22=5/2 30=9/1
23=3/1 31=1/59 32=1/39 33=1/19
D–22
Revision 13
MN-CDM625
Query
Response to Response to
(Instruction &
Command
Qualifier)
RDR= RDR? RDR=xxxxx.xxx
RDR?
RDR* (see Description of
RDR# Arguments)
RSR= RSR? RSR=ddddd.ddd
RSR? (see Description of
RSR* Arguments)
RSR#
RFQ= RFQ? RFQ=xxxx.xxxx
RFQ? (see Description of
RFQ* Arguments)
RFQ#
Exception –
600 Emulation:
RFQ=xxx.xxxx
RMX? RMX? RMX=x
RMX=
RMX* (see Description of
RMX# Arguments)
RMR? RMR? RMR=xx
RMR=
RMR* (see Description of
RMR# Arguments)
Query
