CDM-625 Advanced Satellite Modem
Appendix F
F.5.1.2
Home > Outdoor Unit (ODU) Submenu
After configuring the CDM-625 for 70/140 MHz operation, you may use the 'ODU (Outdoor
Unit)' pages to control and monitor the CSAT-5060 Outdoor Unit that is connected via FSK to the
CDM-625.
Open the Outdoor Unit (ODU) submenu from the Home menu. This submenu contains the
following options:
Hot
Dialog Window
Key
A
ODU Comms Enabled
B
CSAT-5060
Press a hot key to open the dialog window or the submenu. Otherwise, press [ESC] to return to
the Home submenu.
Option Entry
Use the ↑↓ arrow keys to select Disabled or Enabled
Open the CSAT-5060 submenu – See Sect. F.5.1.2.1
F–56
Revision 13
MN-CDM625
