Comtech EF Data CDM-625 Installation And Operation Manual page 429

CDM-625 Advanced Satellite Modem
IP Packet Processor Option
Step Task
2 The illustration a t r ight i dentifies t he u pgrade l ocations
within the chassis for:
Installation of the fan into the chassis;
•
Plug-in of both the fan power cable and IP Packet
•
Processor Card into the modem's framing board;
Assembly of the IP Packet Processor Card onto
•
the chassis-mounted card bosses.
3 Unplug t he f ront p anel r ibbon c able f rom i ts c onnector o n
the modem's framing board, and then move the cable out of
the way of the upgrade location.
