Comtech EF Data CDM-625 Installation And Operation Manual page 532

CDM-625 Advanced Satellite Modem
Appendix D
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Delete entry in SVD= 4 bytes
VLAN table
Packet PPE= 1 byte, value
Processor 0 or 1
Card Enable
QoS Mode QOS= 2 bytes
Switch Ports SPC= 47 bytes
Configuration
Description of Arguments
Command only.
Deletes VLAN table entry in the form aaaa, where:
aaaa = the VLAN ID number in the range 0001-4095.
Command or Query.
Packet Processor Card Enable, in the form PPE=x, where:
0 = Packet Processor Card is Disabled
1 = Packet Processor Card is Enabled
Note: Change of this configuration results in modem auto-reboot only when IP Packet Processor option card
is installed and enabled. Otherwise, when the IP Packet Processor option card is not installed, this selection
is stored but is otherwise non-functional.
Command or Query.
Qo (Quality of Service) Mode, in the form QOS=ab where:
a = Layer 2 QoS;
0 = Off, Layer 2 QoS is disabled
1 = VLAN Priority only
2 = Port Priority only
3 = VLAN and Port Priority
b =Layer 3 QoS;
0 = Off, Layer 3 QoS is disabled
1 = Advanced QoS Max / Priority (requires Advanced QoS FAST Option)*
2 = Advanced QoS Min Max (requires Advanced QoS FAST Option)*
3 = Advanced QoS DiffServ (requires Advanced QoS FAST Option)*
*Note: Layer 3 QoS settings 1 through 3 apply to modem only with IP Packet Processor option card installed
and enabled.
Command or Query.
Sets/Returns Ethernet switch ports' priority and PVID in the form
1abccccdxxx;2abccccdxxx;3abccccdxxx;4abccccdxxx, where:
1, 2. 3. 4 = Port number.
a = Port priority;
Value is 1, 2, 3 or 4 (the higher the number, the higher the priority).
b = Port Native Mode;
0 = Native Mode Disabled, 1 = Native Mode Enabled.
cccc = Port VLAN ID in the range of 0000-4095;
Value 0000 is only valid when port Native Mode is disabled.
d = Pause flow control;
0 = Off, 1 = On
xxx = Eeserved.
D–62
Revision 13
MN-CDM625
Query
Response to Response to
(Instruction &
Command
Qualifier)
SVD= N/A SVD=aaaa
SVD? (see Description of
SVD* Arguments)
SVD#
PPE= PPE? PPE=x
PPE? (see Description of
PPE* Arguments)
PPE#
QOS= QOS? QOS=ab
QOS? (see Description of
QOS* Arguments)
QOS#
SPC= SPC? SPC=1abccccdxxx,2
SPC? abccccdxxx,3abcccc
SPC* dxxx,4abccccdxxx
SPC# (see Description of
Arguments)
Query
