CDM-625 Advanced Satellite Modem
Appendix E
E.3.2.2 Home > Administration > SNMP
Open the SNMP page from the Administration submenu. This page contains the following
options:
Hot
Dialog Window
Key
A
Contact
B
Name
C
Location
D
Enable Authentication Traps
E
SNMP Trap Destination IP Address 1
F
SNMP Trap Destination IP Address 2
G
SNMP Trap Version
H
SNMP Trap Community
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Administration
submenu.
Option Entry
Typical for each entry – Enter the desired designations
Use the ↑↓ arrow keys to select Enabled or Disabled
Typical for either entry – Enter either IP Address in the form
XXX.XXX.XXX.XXX
Use the ↑↓ arrow keys to select SNMP V1 or SNMP V2
Enter the desired Trap Community name – the default name is
comtech
E–14
Revision 13
MN-CDM625
