CDM-625 Advanced Satellite Modem
Ethernet-based Remote Product Management
o SMTP Domain Name – Specify the domain of the e-mail server (usually found to the
right of the @ symbol in an e-mail address).
o SMTP Domain Destination – Specify the e-mail recipient name (usually found to the left
of the @ symbol in an e-mail address).
Host Access List
IP (#) / Mask – The Host Access List allows a user to define which remote clients can connect
•
when the Access List is Enabled. Each entry allows a user to specify an IP Address and a
subnet mask to define a unique class of machines that are allowed access.
For example, if a user wanted to grant access to a PC with an IP Address of 10.10.10.1 and
any PC on a subnet of 192.168.10.XXX, and then the Access List would be defined as:
The check box before the IP (#) / Mask must be checked in order for that list
entry to take effect.
•
Access List – The Access List allows a user to grant access via HTTP and SNMP to a defined
list of client machines.
Use the drop-down to select Enable or Disable. If Disable is selected, then any client
machine will be able to connect via HTTP and SNMP.
Click [Submit Admin] to save these settings.
IP 1 / Mask – 10.10.10.1/32
IP 2 / Mask – 192.168.10.0/24
6–17
Revision 13
MN-CDM625
