CDM-625 Advanced Satellite Modem
Ethernet-based Remote Product Management
6.5.4.4.5

Status | Performance Pages

These pages are available only when the optional IP Packet Processor card is
installed and enabled. See Sect. 6.5.3.1 for complete details about using these
conditional access pages.
Click the Performance or Graphs tab to continue.

6.5.4.4.5.1 Status | Performance | Performance

Use this page to view a tabulated "snapshot" of the CDM-625 performance statistics.
CPU Usage
Component
Kernel
Applications
Total
At present, 'CPU Usage (%)' is the only viewable parameter; more functionality will
be selectable in future firmware releases.

Figure 6-46. Status | Performance | Performance page

% CPU Description
The percentage of CPU time used by the packet-processing components of
the module.
The percentage of CPU time used by the management interfaces.
Cumulative percentage of Kernel and Applications components.
