D.5.4 Unit Parameters
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Local/ LRS= 1 byte, 0 to 3
Remote
Status
Modem EMU= 1 byte, value
Emulation 0,1 or 2
Front Panel FPL= 1 byte, numeric Command or Query.
Lockout
Software IMG= 1 byte, value of
Image 1 or 2
Circuit ID CID= 40 bytes
String
RTC Date DAY= 6 bytes
Description of Arguments
Command or Query.
Used set the user's Local/Remote status in the form x, where:
0=Local
1=Serial Remote (RS-232/RS-485)
2=reserved
3=Ethernet Remote
Example: LRS=1 (selects Serial Remote)
Command or Query.
The CDM-625 is designed to be a ' drop-in' replacement for the CDM-600 or CDM-600L modems. In order
for c omplete modem E mulation, al l par ameters, i ncluding t he E ID (equipment I D) mus t be t hat of t he
modem it is emulating. This parameter permits the CDM-625 modem to be configured that way.
The format for the argument is x, where x is:
0= full capability CDM-625 modem (default)
1= to emulate the CDM-600 modem
2= to emulate the CDM-600L modem
Control the state of front-panel lockout in the form x, where:
0= no lockout
1= front panel lockout active.
Disable the lockout by either FPL=0, or by setting into local mode using LRS=0.
Command or Query.
Active software image in the form x, where:
1=Bulk Image #1 currently active
2=Bulk Image #2 currently active
Command or Query.
Sets or queries the user-defined Circuit ID string, which is a fixed length of 40 characters.
Valid characters include:
Space ( ) * + – , . / 0 9 and A thru Z
Command or Query.
A date in the form ddmmyy (European format), where
dd = day of the month (01 to 31)
mm = month (01 to 12)
yy = year (00 to 99)
Example: DAY=240457 (April 24, 2057)
D–27
Revision 13
MN-CDM625
Query
Response to Response to
(Instruction &
Command
Qualifier)
LRS LRS? LRS=x
LRS? (see Description of
LRS* Arguments)
LRS#
EMU= EMU? EMU=x
EMU? (see Description of
EMU* Arguments)
EMU#
FPL= FPL? FPL=x
FPL? (see Description of
FPL* Arguments)
FPL#
IMG= IMG? IMG=x
IMG? (see Description of
IMG* Arguments)
IMG#
CID= CID? CID=x
CID? (see Description of
CID* Arguments)
CID#
DAY= DAY? DAY=ddmmyy
DAY? (see Description of
DAY* Arguments)
DAY#
