Comtech EF Data CDM-625 Installation And Operation Manual page 531

CDM-625 Advanced Satellite Modem
Appendix D
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Ethernet EGC= Up to 347
Global bytes
Configuration
VLAN Mode SVM= 1 byte, value
Enable 0 or 1
Switch MAC SML= 1byte, value
Learning 0 or 1
VLAN Table SVT= Up to 287
byes
Add entry to SVA= 8 bytes
VLAN table
Management SMV= 4 bytes
VLAN ID
Description of Arguments
Command or Query.
Global Configuration of CDM625 Ethernet, in the form shown in the Response to Query column, where:
1abccccdxxx;2abccccdxxx;3abccccdxxx;4abccccdxxx=Switch Ports configuration
D=VLAN Mode Enable
E=Switch MAC Learning
FF=QoS Priority
G= Ethernet 2048 Frame Size
H= Precision Time Protocol Feature
I= Precision Time Protocol Mode
J= Carrier ID
KKKK=Management VLAN ID
LLLL....=VLAN Table
Command or Query.
VLAN Mode Enable, in the form x, where:
0 = VLAN is Disabled
1 = VLAN is Enabled
Command or Query.
Switch MAC learning in the form x, where:
0 = Off
1 =On
Command or Query.
Sets/Returns all the entries in the VLAN table in the form aaaabcde,aaaabcde,aaaabcde,..., where:
aaaa = VLAN ID. Value range is 1-4095, must not be duplicate of any PVID.
b = property of port 1: 0=Tagged, 1=Filtered, 2=Untagged
c = property of port 2: 0=Tagged, 1=Filtered, 2=Untagged
d = property of port 3: 0=Tagged, 1=Filtered, 2=Untagged
e = property of port 4: 0=Tagged, 1=Filtered, 2=Untagged
Command only.
Adds entry to VLAN table in the form aaaabcde, where:
aaaa = New VLAN ID. Value range is 1-4095, must not be duplicate of any PVID or VLAN ID existing in
VLAN table.
b = property of port 1. 0=Tagged, 1=Filtered, 2=Untagged
c = property of port 2. 0=Tagged, 1=Filtered, 2=Untagged
d = property of port 3. 0=Tagged, 1=Filtered, 2=Untagged
e = property of port 4. 0=Tagged, 1=Filtered, 2=Untagged
Command or Query.
Management Port's VLAN ID in the form aaaa, where:
aaaa = the ID number in the range 0001-4095.
same as SPC
same as SVM
same as SML
same as QOS
same as EFS
same as PTP
same as PTM
same as CAI
same as SMV
same as SVT
D–61
Revision 13
MN-CDM625
Query
Response to Response to
(Instruction &
Command
Qualifier)
EGC= EGC? EGC=1abccccdxxx;2
EGC? EGC?n (where n abccccdxxx;3abcccc
EGC* = 0 to 9. Returns dxxx;4abccccdxxxD
EGC# the EGC portion EFFGHIJKKKKLLLL
of 1 of 10 stored ....
configurations) (see Description of
Arguments)
SVM= SVM? SVM=x
SVM? (see Description of
SVM* Arguments)
SVM#
SML= SML? SML=x
SML? (see Description of
SML* Arguments)
SML#
SVT= SVT? SVT=aaaabcde,aaa
SVT? abcde,aaaabcde...
SVT* (see Description of
SVT# Arguments)
SVA= N/A SVA=aaaabcde
SVA? (see Description of
SVA* Arguments)
SVA#
SMV= SMV? SMV=aaaa
SMV? (see Description of
SMV* Arguments)
SMV#
Query
