Comtech EF Data CDM-625 Installation And Operation Manual page 507

CDM-625 Advanced Satellite Modem
Appendix D
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Tx BERT BTX= 1 byte, value of
State 0 or 1
Rx BERT BRX= 1 byte, value of
State 0 or 1
Tx BERT TBP= 1 byte
Pattern
Rx BERT RBP= 1 byte
Pattern
Description of Arguments
Command or Query.
Tx BERT State in the form x, where:
0 = Off
1 = On
Example: BTX=1 (Tx BERT On)
Command or Query.
Rx BERT State in the form x, where:
0 = Off
1 = On
Example: BRX=1 (Rx BERT On)
Command or Query.
Tx BERT Pattern, in the form x, where:
0=space
1=mark
2=1:1
3=1:2
4=63
5=511
6=2047 (default)
7=2047R (or 2047 Alternate)
8=Mil-188
9=2^15-1
A=2^20-1
B=2^23-1
Example: TBP=6 (Tx BERT Pattern is 2047)
Command or Query.
Rx BERT Pattern, in the form x, where:
0=space
1=mark
2=1:1
3=1:2
4=63
5=511
6=2047 (default)
7=2047R (or 2047 Alternate)
8=Mil-188
9=2^15-1
A=2^20-1
B=2^23-1
Example: RBP=6 (Rx BERT Pattern is 2047)
D–37
Revision 13
MN-CDM625
Query
Response to Response to
(Instruction &
Command
Qualifier)
BTX= BTX? BTX=x
BTX? (see Description of
BTX# Arguments)
BRX= BRX? BRX=x
BRX? (see Description of
BRX# Arguments)
TBP= TBP? TBP=x
TBP? (see Description of
TBP# Arguments)
RBP= RBP? RBP=x
RBP? (see Description of
RBP# Arguments)
Query
