CDM-625 Advanced Satellite Modem
Rear Panel Connectors and Pinouts
3.2.3.4

1:1 Control (DB-9F)

The 1:1 Control connector is intended only for connection to a CRS-170A or CRS-180
Redundancy Switch.
3.2.3.5

Ext Ref In/Out

The 1:1 Control connector is a 9-pin Type 'D' female connector.

Table 3-14. 1:1 Control Interface Connector Pinouts

Pin #
Description
(R-L)
1
Ground
6
Transmit Serial Data – auxiliary channel
2
Receive Serial Data – auxiliary channel
Redundancy Out 1
7
Redundancy In 1
3
Redundancy Out 2
8
Redundancy In 2
4
Fused +12 volt Out
9
5
Ground
Connector Type
Description
BNC
External Reference
3–14
Revision 13
MN-CDM625
Direction
Out
In
Out
In
Out
In
Out
Direction
In/Out
