CDM-625 Advanced Satellite Modem
Appendix E
E.3.7 Home > Redundancy Submenu
Open the Redundancy submenu from the Home menu. This submenu additionally displays the
status of the redundant modem setup. The redundant modem operation options are as follows:
Hot
Dialog Window
Key
A Traffic IP Address
B Traffic IP Network Prefix
C Redundancy 1-for-N Mode
D Packet Processor Redundancy
E
Force Redundant Switch
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Home
submenu.
Option Entry
Enter an IP address in the form XXX.XXX.XXX.XXX
Enter a value from 8 to 30
Typical for either entry – Use the ↑↓ arrow keys to select
Disabled or Enabled
Use the ↑↓ arrow keys to select No Switch or Force Switch
