CDM-625 Advanced Satellite Modem
Appendix D
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
Initialize
IEP=
None
Stored
Events
Pointer
Statistics
SSI=
1 byte,
Sample
numerical
Interval
Number of
N/A
3 bytes
Unread
stored
Statistics
Retrieve next
N/A
135 bytes
5 unread
Stored
Statistics
Description of Arguments
Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the stored events log.
Command or Query.
Used to set the sample interval for the Statistics Logging Function in the form x, where:
x= 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the statistics logging function.
Example: SSI=3 means 30 minutes
Query only.
Unit returns the number of stored Statistics, which remain Unread (over remote control) in the form xxx,
where:
x = 0-255
Example: NUS=187
Query only.
Unit returns the oldest 5 Stored Statistics, which have not yet been read over the remote control in the reply
format [CR]sub-body[CR]sub-body[CR]sub-body[CR]sub-body[CR]sub-body, where sub-body=
AA.ABB.BC.CD.Dddmmyyhhmmss:
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Max. Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
ddmmyy = date stamp.
hhmmss = time stamp.
If there are no new events, the unit replies with RNS*. If there are less than 5 statistics to be retrieved, the
remaining positions are padded with zeros.
D–32
Revision 13
MN-CDM625
Query
Response to
Response to
(Instruction &
Command
Qualifier)
IEP=
N/A
N/A
IEP#
SSI=
SSI?
SSI=x
SSI?
(see Description of
SSI*
Arguments)
SSI#
N/A
NUS?
NUS=xxx
(see Description of
Arguments)
N/A
RNS?
RNS=[CR]AA.ABB.
BC.CD.Dddmmyyhh
mmss[CR]AA.ABB.
BC.CD.Dddmmyyhh
mmss[CR]AA.ABB.
BC.CD.Dddmmyyhh
mmss[CR]AA.ABB.
BC.CD.Dddmmyyhh
mmss[CR]AA.ABB.
BC.CD.Dddmmyyhh
mmss
(see Description of
Arguments)
