CDM-625 Advanced Satellite Modem
Appendix E
Hot
Dialog Window
Key
I
Tx Backward Alarm Enable Port1
J
Tx Backward Alarm Enable Port2
K
Tx Backward Alarm Enable Port3
L
Tx Backward Alarm Enable Port4
M
Rx Backward Alarm Enable Port1
N
Rx Backward Alarm Enable Port2
O
Rx Backward Alarm Enable Port3
P
Tx Backward Alarm Enable Port4
Q
AUPC Enable
R
AUPC Remote Demod Target Eb No
S
AUPC Tx Power Max Increase
T
AUPC Action On Max Power
AUPC Action On Remote Demod
U
Unlock
V
EDMAC Mode
W
EDMAC Address
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
Option Entry
Typical for each entry – Use the ↑↓ arrow keys to select Off or On
Use the ↑↓ arrow keys to select Disable or Enable
Enter a value from 0.0 to 14.9 dB
Enter a value from 0 to 9 dB
Use the ↑↓ arrow keys to select No Action, Generate Tx Alarm
Max Power, or Generate Tx Alarm Minimum ModCod
Use the ↑↓ arrow keys to select Go To Nominal Power, Go To
Max Power, or Hold
Use the ↑↓ arrow keys to select Off, Master, or Slave
Enter a value from 0 to 9999
E–39
Revision 13
MN-CDM625
