CDM-625 Advanced Satellite Modem
Preface
•
For AC operation, the unit requires two common 4 Amp/250 volts 20mm x 5mm Slow-
blow fuses that are contained within a fuse holder that is press-fit into the body of the
IEC power inlet module (on the rear panel of the unit).
•
For DC operation, the unit requires two different fuses that are contained within the
individual screw-in receptacles below the terminal block (on the rear panel of the unit).
These DC fuse requirements are as follows:
o Modem Operation – 3 Amp/250 volts 20mm x 5mm Slow-blow fuse.
o BUC Operation – 6.3 Amp/250 volts 20mm x 5mm Slow-blow fuse.
Operating Environment
DO NOT OPERATE THE UNIT IN ANY OF THESE EXTREME OPERATING
CONDITIONS:
•
•
•
•
•
•
European Union Radio Equipment and Telecommunications Terminal
Equipment (R&TTE) Directive (1999/5/EC) and EN 301 489-1
Independent testing verifies that the unit complies with the European Union R&TTE Directive, its
reference to EN 301 489-1 (Electromagnetic compatibility and Radio spectrum Matters [ERM];
ElectroMagnetic Compatibility [EMC] standard for radio equipment and services, Part 1:
Common technical requirements), and the Declarations of Conformity for the applicable
directives, standards, and practices that follow:
European
Union
(2004/108/EC)
•
Emissions: EN 55022 Class B – Limits and Methods of Measurement of Radio
Interference Characteristics of Information Technology Equipment.
AMBIENT TEMPERATURES LESS THAN 0°C (32°F) OR MORE THAN 50°C
(122°F). (MAXIMUM STORAGE TEMPERATURE ALLOWED IS -25°C
(-13°F) TO 85°C (185°F)).
PRECIPITATION, CONDENSATION, OR HUMID ATMOSPHERES OF MORE
THAN 95% RELATIVE HUMIDITY.
UNPRESSURIZED ALTITUDES OF MORE THAN 2000 METRES (6561.7
FEET).
EXCESSIVE DUST.
FLAMMABLE GASES.
CORROSIVE OR EXPLOSIVE ATMOSPHERES.
Electromagnetic
Compatibility
xxx
Revision 13
MN-CDM625
(EMC)
Directive
