CDM-625 Advanced Satellite Modem
Appendix E
E.3.3.1 Home > Modem > Interface
Open the Interface page from the Modem submenu. This page contains the following options:
Hot
Dialog Window
Key
A Tx Interface Type
C Rx Interface Type
B Tx Framing Mode
D
Rx Framing Mode
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
Option Entry
Typical for either entry – Use the ↑↓ arrow keys to select:
• RS-422 • V.35
• G.703 Unbalanced • Audio
• HSSI • IP
• IP ACM
Typical for either entry – Use the ↑↓ arrow keys to select:
• Unframed • IBS
• DNI • EDMAC
• ESC ++ • EDMAC2
• Frm QDI • EDMAC3
E–23
Revision 13
MN-CDM625
• G.703 Balanced
• LVDS
• ASI
• IDR
• DNI ++
• ODI
