CDM-625 Advanced Satellite Modem
Front Panel Operation
CONFIG: Tx  Power  Mode  AUPC
5.2.1.3.3.1
The AUPC Output Power Mode Is selectable only when the T0x framing is EDMAC, D&I++, ESC++
or D&I. Otherwise, if you attempt to select the Output Power Mode as AUPC, you are blocked
from selecting AUPC and a message displays on the bottom line:
Output Power: Mode= AUPC
! AUPC needs supporting framing mode
Otherwise, with an appropriate framing type selected, the bottom line appears as shown:
Output Power: Mode= AUPC
Target-EbNo-Range
Use the ◄ ► arrow keys to select Target-EbNo-Range or Alarm-Action and then press ENTER.
CONFIG: Tx  Power  Mode  AUPC  Target-EbNo-Range
Minimum EbNo of Remote Modem = 5.0dB
Max Permitted Power Increase = 9dB ()
On the top line – To edit the Target Eb/No of the remote modem, use the
select a digit to edit, and then use the
3.0 dB. The upper limit is 14.9 dB.
On the bottom line – To edit the maximum permitted increase in power level when in AUPC
Mode, use the
change that digit. Press ENTER when done. The default value is 1 dB. The upper limit is 9 dB,
except when CnC Mode is ON – the upper limit value is instead 3 dB.
Press ENTER when done.
CONFIG: Tx  Power  Mode  AUPC  Alarm-Action
Max Tx Pwr Action= None
Rem Demod Unlock Act= Nom-Pwr (Nom,Max)
On the top line
power level to be reached, use the
On the bottom line
the arrow keys to select Nom-Pwr or Max-Pwr. Note the following:
▲▼
Chapter 8. AUTOMATIC UPLINK POWER CONTROL (AUPC)
▲▼
◄ ► arrow keys to select a digit to edit, and then use the
To determine the action that occurs if the AUPC causes the maximum output
–
▲▼
To determine the action that occurs if the remote demod is unlocked, use
–
(Manual,AUPC)
(Manual,AUPC)
Alarm-Action
arrow keys to change that digit. The default value is
(None, Tx-Alm)
arrow keys to select None or Tx Alarm.
5–14
Revision 13
MN-CDM625
!
()
◄ ► arrow keys to
arrow keys to
▲▼
