CDM-625 Advanced Satellite Modem
Appendix D
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
1:N (One For OFN= 1 byte, 0 or 1
N) control
IP Address IPA= 18 bytes
numerical
IP Gateway IPG= 15 bytes
numerical
Traffic IP IPT= 18 bytes
Address numerical
MAC Address N/A 12 bytes,
alpha-
numerical
Description of Arguments
Command or Query.
Enables or disables the 1:N control. This affects a control line on the 25-pin rear panel connector. This must
be enabled when the modem is attached to a CRS-300 1:N Controller or a CRS-500 1:N Switch in the form
x, where:
0=Disabled
1=Enabled
Example: OFN=0 (selects Disabled)
Command or Query.
Used to set the IP Address and network prefix for the 10/100 Base T Ethernet management port, in the form
aaa.bbb.ccc.ddd.yy, where permitted ranges are:
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 001-255
yy=08-30
Example: IPA=010.006.030.001.24
Command or Query.
Used to set the IP Gateway Address for the Ethernet management port, in the form aaa.bbb.ccc.ddd, where
permitted ranges are:
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 001-255
Example: IPG=010.006.030.001
Command or Query.
In a 1:1 system, each modem has its own unique IP address that would be used by an external M&C
application to address each modem. The IP traffic uses a different address, and whichever modem is
online, uses this address for the IP traffic in the form aaa.bbb.ccc.ddd.yy where permitted ranges are:
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 001-255.
yy is the Subnet Mask Length (range: 08 to 30)
Example: IPT=010.006.030.002.24
Query only.
Used to query the unique MAC Address for the modem.
Example: MAC=0006B00001C2
D–34
Revision 13
MN-CDM625
Query
Response to Response to
(Instruction &
Command
Qualifier)
OFN= OFN? OFN=x
OFN? (see Description of
OFN* Arguments)
OFN#
IPA= IPA? IPA=
IPA? aaa.bbb.ccc.ddd.yy
IPA* (see Description of
IPA# Arguments)
IPG= IPG? IPG=
IPG? aaa.bbb.ccc.ddd
IPG* (see Description of
IPG# Arguments)
IPT= IPT? IPT=
IPT? aaa.bbb.ccc.ddd.yy
IPT* (see Description of
IPT# Arguments)
N/A MAC? MAC=aabbccddeeff
(see Description of
Arguments)
Query
