CDM-625 Advanced Satellite Modem
Appendix E
E.3.4.4 Home > Network > VLAN
Open the VLAN submenu from the Network submenu. This submenu contains the following
options:
Hot
Dialog Window
Key
A VLAN Table
B
VLAN Mode Enable
C
Ethernet Management PVID
Press a hot key to open the VLAN Table or a dialog window. Otherwise, press [ESC] to return to
the Network submenu.
Option Entry
Use the ↑↓ arrow keys to select a table – see Sect. E.3.4.4.1
Use the ↑↓ arrow keys to select Disabled or Enabled
Enter a value from 1 to 4095
E–46
Revision 13
MN-CDM625
